| Power Input | 12-30 V DC regulated (via 2-pin connector) |
| Camera Interface | 30-pin LVDS (Single mode) micro-coaxial interface |
| MIPI CSI-2 Output | 4-lane MIPI CSI-2 (Mini-SAS Connector) |
| Supported Video Format | Up to Full HD 1080p 60fps (camera-dependent) |
| Camera Control | VISCA over UART (3.3 V CMOS) bridged to I²C (host), Optional RS-422 control interface |
| Indicators | Power LED (Green) |
| Board Dimensions (L × W) | 50 mm × 50 mm |
| Weight | Approx. 15 g |
| Operating Temperature | –20 °C to +85 °C |
| Compliance | MIPI CSI-2 Specification, RoHS |
| Recommended Supply | 12 V DC, 1.5 A |
| Camera Compatibility (H/W pinout) | LVDS Block Cameras (Sony, Tamron, KT&C, Videology, Wonwoo and Skoopia) |
| Supported Host Platforms | NXP i.MX8M Plus (8MPLUSLPD4-EVK evaluation kit) |
