| Input Voltage | 12 V DC regulated (via 2-pin connector) |
| Input Current | Approx. 0.5 A typical (1.5 A max with camera) |
| Camera Interface | 30-pin micro-coax (Sony FCB-ER8530, FCB-ER9500 and FCB-EW9500H pinout) |
| MIPI CSI-2 Output | 4-lane CSI-2 (FFC/FPC) |
| Supported Video Format | Up to Full HD 4k @ 60 fps (Camera dependent) |
| Camera Control | VISCA over UART (3.3 V CMOS) bridged to I²C (host) |
| Indicators | Power LED (Green) |
| Board Dimensions (L × W) | 50 mm × 50 mm |
| Weight | 11.8 g |
| Operating Temperature | –20 °C to +85 °C |
| Compliance | MIPI CSI-2 Specification, RoHS |
| Recommended Supply | 12 V / 1.5 A regulated |
| Compatibility | Sony FCB-ER HDMI Cameras |
| Host Platforms Supported | Raspberry Pi 5 |
