| Module | NVIDIA Orin Nano/NX |
| Storage | NVMe SSD via M.2 Key M 2242 |
| Camera Interfaces | 1 × LVDS (Sony FCB or Tamron or KT&C), optional HDMI (Sony FCB-ER series) via bridge board through 22pin MIPI CSI-2 connector |
| Network Interface | 1 Gbps Ethernet via Molex Pico clasp 1.0 mm connector and M.2 Key E (WiFi/BT) 2230 |
| Expansion Header | I²C, UART x 2, RS422 (Optional), CAN, SPI & GPIO via Molex Pico clasp 1.0 mm connector |
| Video Output | Micro HDMI |
| USB Interface | USB Type-C (USB2 & USB3) for flashing, debugging & data, and 1 × USB 2.0 via Samtec Micro Tiger-eye connector |
| UART Channels | Independent dedicated UART channel for camera VISCA control via KEL connector |
| RTC | Onboard RTC battery connector |
| Power Input | Molex Micro-Fit Plus connector, 12–19 V regulated, supports Super mode |
| Fan | Dedicated PWM-controlled onboard fan |
| Operating Temperature | –20 °C to +85 °C |
| Dimensions (L × W) | 90 × 60 mm |
| Weight | 38.1 g |
| Compliance | RoHS |
