Surgical 4K Camera - High Quality 4K Wireless Streaming
Modern operating rooms demand high-quality visualization, flexibility, and unrestricted mobility. Traditional wired HDMI camera systems restrict placement, create cable clutter, and complicate installation around OT lights.
To overcome these limitations, Oppila’s Wireless Surgical 4K Camera Solution for OT Lights integrates Sony FCB block cameras with ultra-low-latency wireless transmission, delivering 4K30 real-time video without a single signal cable.
This solution enables surgeons and medical teams to experience crystal-clear, lag-free surgical visualization, while providing complete freedom in OT equipment placement.
Product Overview
Oppila’s Wireless Surgical 4K Camera System combines:
- Sony FCB-series block cameras (e.g., FCB-ER8530)
- Oppila’s custom wireless transmitter (TX) & receiver (RX)
- Low-latency codec & transport architecture
- Camera control features (Zoom, Focus, White Balance, etc.)
The system supports 4K@30 FPS wireless video transmission with near-zero latency (~50 ms end-to-end), including:
- Encoding
- Wireless streaming
- Decoding
Developed specifically for Operating Theatres (OT), the system ensures:
- Cable-free installation
- Zero visual loss
- Real-time surgical documentation
- Surgeon-controlled camera operation
Key Features
1. High Performance Wireless Streaming
- End-to-end latency: as low as 50 ms
- Includes compression, wireless transmission & decoding
- Designed for real-time medical workflows
2. Video Quality:
- Visually lossless 4K30
- Suitable for surgical recording & live telemedicine
3. Audio Support
- Integrated audio feedback
- Enhances communication between OT staff and teaching environments
4. Connectivity Options
✓ Wireless Transmission (Primary Mode)
- Ultra-stable, near-zero latency wireless streaming.
✓ Ethernet Transmission (Optional Mode)
- Uses HDMI-over-IP architecture for long-distance wired streaming.
5. Control Functionality
-
Touchscreen interface (RX side)
-
IR remote control
-
Access full VISCA control of the Sony FCB camera:
- Zoom in/out
- Focus control
- White balance presets
- Exposure control
- Picture enhancements
6. Resolution Support
- Up to 4K @ 30 FPS
- Optimized for Sony FCB-ER8530 and similar models
7. Additional Features
-
Cross-platform viewing:
- Android / iOS devices (with expected latency variations)
-
High video quality equivalent to uncompressed HDMI
-
Stable even in crowded wireless spectrum
-
Works with standard routers
-
Supports multi-cast and multi-receiver configurations
Sony FCB-ER8530 Camera Specifications
The wireless solution is optimized for Sony’s 4K block cameras.
Highlights of FCB-ER8530:
- 1/2.5-Type Exmor R CMOS sensor with 8.5 MP
- 20× optical zoom
- 4K HDMI output
- Wide field of view: 70.2° to 4.1°
- 0.4 lx minimum illumination
- 0.1 sec focus movement
- 16-step aperture control
- Multiple white balance modes
- VISCA control support
- Power: 7V – 12V DC, 4.4 W consumption
This makes it ideal for OT lighting environments, surgical detail visualization, and medical teaching applications.
System Power Requirements :
Transmitter (TX): 12 V input
Receiver (RX): 12 V input
Both modules are designed for hospital-grade reliability and continuous operation.
Why Oppila’s Wireless Surgical 4K Camera Solution for OT Lights?
- Eliminates cable clutter in sensitive medical spaces
- True plug-and-play installation
- Zero compromise on video quality
- Fully supports Sony FCB camera controls
- Superior stability even in congested wireless environments
- Supports multi-screen and multi-monitor setups
This solution transforms surgical visualization by providing freedom, clarity, and reliability.
Conclusion
Oppila’s Wireless Surgical 4K Camera Solution for OT Lights pairs the precision optics of Sony FCB block cameras with our advanced wireless streaming hardware.
With near-zero latency, lossless 4K video, multi-receiver support, and comprehensive camera control, this system delivers the performance required for:
- Surgical documentation
- Live teaching
- Medical training
- Operating theatre integration
- Telemedicine
It is a future-ready solution enabling hospitals to transition toward wireless, flexible, modern OT environments.
To know more, visit: https://www.oppila.in/products/wireless-4k-camera
FAQs
It is a wireless video transmission system that streams 4K30 video from Sony FCB cameras with near-zero latency, eliminating all signal cables in the operating theatre.
It supports all HDMI-output FCB models, especially Sony FCB-ER8530.
Approximately 50 ms, including encoding, wireless transmission, and decoding.
No. The system delivers visually lossless 4K30 video comparable to uncompressed HDMI.
Yes, it is designed specifically for operating theatres (OT) and medical imaging.
Yes, it is engineered to remain stable even in congested RF environments.
You can use: Touchscreen (RX side), IR Remote, and VISCA camera control.
Zoom, focus, exposure, white balance, aperture, and more.
Yes. It supports HDMI-over-IP for wired installations.
Yes, the system supports multi-cast and multiple receivers.
Up to 4K at 30 fps.
Yes, it works with Android and iOS (latency depends on device capabilities).
No. Only power cables are needed for TX/RX. Video transmission is completely wireless.
The wireless range depends on the router/antenna but supports long-distance, stable streaming in hospital environments.
Yes, full VISCA control is supported for camera operations.
Both transmitter (TX) and receiver (RX) use 12V DC input.
Yes, the 4K visually lossless output is ideal for medical teaching and live demonstrations.
Yes. It is designed for continuous operation in medical environments.
Because it offers: No cable clutter, Flexible OT installation, Near-zero latency, Multi-display support, and High-quality 4K visual fidelity.
