| Specifications | Details |
| Imager | 1/1.8 Type STARVIS CMOS Sensor |
| Picture Elements | 4170K pixels |
| Lens | f= 6.5 mm (WIDE) to 162.5 mm (TELE), F1.6 to F4.8 (Typical value) |
| Zoom Movement Speed | WIDE – TELE: 4.8 sec (Focus Tracking On), 2.8 sec (Focus Tracking Off) WIDE – Digital TELE (Digital 12×): 6.1 sec (29.97p/59.94p mode), 6.4 sec (25p/50p mode) Digital WIDE – Digital TELE (Digital 12×): 1.4 sec (29.97p/59.94p mode), 1.6 sec (25p/50p mode) |
| Focus Movement Time | ∞ to Near 1.4 sec |
| Zoom | Enhanced optical zoom 30× Digital Zoom 12× (max. 432× with StableZoom) |
| Angle of view (H) | Approx. 58.1 degrees (Wide end), approx. 2.3 degrees (Tele end) |
| Min. Working Distance | 100 mm (Wide end), 1200 mm (Tele end) |
| Min. Illumination | In the case of ICR-Off: 0.009 lx (1/30 sec, 50%, High Sensitivity mode On) 0.09 lx (1/30 sec, 50%, High Sensitivity mode Off) 0.0012 lx (1/4 sec, 1/3 sec, 50%, High Sensitivity mode On) 0.012 lx (1/4 sec, 1/3 sec, 50%, High Sensitivity mode Off) In the case of ICR-On: 0.00008 lx (1/30 sec, 50%, High Sensitivity mode On) 0.00063 lx (1/30 sec, 50%, High Sensitivity mode Off) 0.000005 lx (1/4 sec, 1/3 sec, 30%, High Sensitivity mode On) |
| Sync System | Internal |
| Recommended Illumination | 100 lx to 100,000 lx |
| Image S/N | 50 dB (Weight On) |
| Back Light Compensation | On/Off |
| Electronic Shutter Speed | 1/1 sec to 1/10000 sec (22 steps) |
| White Balance | Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto) |
| Gain | Auto/Manual (0 to 50.0 dB (0 to 28 step)), Max. Gain Limit (10.7 to 50.0 dB (6 to 28 step)) |
| Wide Dynamic Range Mode | On/Off |
| Noise Reduction | On/Off (level 5 to 1 / Off, 6 steps) |
| Defog | On/Off (low, mid, high) |
| Aperture Control | 16 steps |
| Preset | 16 positions |
| Camera Control Interface | VISCA protocol (CMOS 3.3 V level, 5.5 V tolerant) 9.6 kbps, 19.2 kbps, 38.4 kbps, 115.2 kbps, Stop bit, 1 bit |
| Video Output | Digital (MIPI) |
| Storage Temperature/Humidity | –20 °C to +60 °C (–4 °F to +140 °F) / 20% to 95%, Absolute humidity: 36 g/m³ |
| Operating Temperature/Humidity | –5 °C to +60 °C (23 °F to +140 °F) / 20% to 80%, Absolute humidity: 36 g/m³ |
| Power Requirements | 7 V to 12 V DC |
| Power Consumption | 5.0 W (during motor operation: 6.8 W) |
| Mass | Approx. 439 g (15 oz.) |
| Dimensions | 56 × 64 × 125 mm (2 1/4 × 2 5/8 × 5 in.) (W/H/D) |
