| Specifications |
Details |
| Camera Compatibility |
Sony FCB-ER8530, FCB-EW9500H |
| Video Output |
HDMI 2.0, 4K UHD (3840 × 2160) @ 30 fps |
| Camera Interface |
30-pin FFC/FPC cable connector |
| Power Supply |
12V DC via RMC2 |
| Power Consumption |
<5W |
| Camera Control |
VISCA over UART (Onboard joystick or external controller) |
| Control Interface |
UART for Camera Protocol |
| Control Interface |
UART for Camera Protocol |
| Dimensions |
50 x 60mm |
| Mounting Holes |
4 × 3mm diameter (standard PCB mounting) |
| Operating Temperature |
-40°C to 85°C |
| Storage Tempeature |
-40°C to 85°C |
