Specifications

• AN231E04 dpASP with header pins
• Optional Rauch filter to level shift and prepare input signal includes single-ended to differential conversion where needed
• Serial (USB) interface that allows ”plug and play” connectivity using a standard serial cable between the development board and a PC running AnadigmDesigner®2 software
• SPI (or host processor) interface, allowing you to interface the dpASP directly to your digital board
• A large breadboard area for building your specific interface circuitry PCB is pre-built with provision the addition resistor and capacitor which can for a Rauch filter at the input or output
• Daisy chain capability – allowing multiple boards to be connected to evaluate multi-chip systems
• On-board 16-MHz or 40MHz clock source for FPAA Analog clock input
• Ideally suited to the development of the embedded system, the board contains a 32bit 80Mhz (3rd Party)microcontroller, 5 pin access to re-program this uC, the board is prepared and wired for a standard 16x2 LCD (Not supplied)
• The development board is supplied with one AN231E04 FPAA’s you can use the board with AnadigmDesigner®2 software Version 2.8.0.2 or later to implement designs for any dpASP or FPAA in the 3.3volt family
