| Specifications | Details |
| Camera Compatibility | Sony FCB-EV9500L, FCB-EV9520L Tamron MP3010M-EV |
| 30-pin KEL Connector | Supports camera integration. |
| Input Type | LVDS (Sony/Tamron Block Cameras) |
| Output Interface | MIPI CSI-2(Compatible with NVIDIA Orin Super Dev Kit) |
| Power Supply | 12-40V DC, 2A |
| Dimensions | 50 x 50mm |
| Operating Temperature | -40°C to 85°C |
| Driver Support | Custom Driver Support available |
| Control Interfaces | Camera UART, Camera Reset via Edge Connector |
