| Specifications | Details |
| Imager | 1/2.5-Type "Exmor R" CMOS Sensor |
| Picture Elements | 8510K pixels |
| Lens | 20× Zoom, f = 4.4 mm (Wide), 88.0 mm (Tele), F2.0 to F3.8 |
| Zoom Movement Speed | Optical Wide – Optical Tele: 3.0 sec (Focus Tracking On) Optical Wide – Super resolution zoom Tele: 3.4 sec Digital Wide – Digital zoom Tele: 5.0 sec |
| Focus Movement Time | ∞ to Near 0.1 sec |
| Digital Zoom | 12× (240× with optical zoom) |
| Angle of View (H) | Approx. 70.2° (Wide end, Image stabilizer Off) Approx. 4.1° (Tele end, Image stabilizer Off) Approx. 60.0° (Wide end, Image stabilizer On) Approx. 3.5° (Tele end, Image stabilizer On) |
| Min. Working Distance | 80 mm (Wide end), 800 mm (Tele end) |
| Min. Illumination | 0.4 lx (1/30 sec, 50%, High Sensitivity mode On) 1.6 lx (1/30 sec, 50%, High Sensitivity mode Off) 0.06 lx (1/4 sec, 50%, High Sensitivity mode On) 0.21 lx (1/4 sec, 50%, High Sensitivity mode Off) |
| Sync System | Internal/External (only FCB-ER8550) |
| Recommended Illumination | 100 lx to 100,000 lx |
| S/N Ratio | 50 dB (Weight On) |
| Back Light Compensation | On/Off |
| Electronic Shutter Speed | 1/1 sec to 1/10000 sec (28 steps) |
| White Balance | Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto) |
| Gain | Auto/Manual (0 to 48 dB in 16 steps), Max. Gain Limit (9 to 48 dB in 12 steps) |
| Noise Reduction | On/Off (level 5 to 1 / Off, 6 steps) |
| Defog Mode | On/Off (Low, Mid, High) |
| Aperture Control | 16 steps |
| Preset | 16 positions |
| Camera Control Interface | VISCA protocol (CMOS 3.1V), PTP USB 9.6 kbps, 19.2 kbps, 38.4 kbps, 115.2 kbps, Stop bit: 1 bit |
| Video Output | Digital (HDMI) |
| Storage Temperature/Humidity | –20 °C to +60 °C (–4 °F to +140 °F) / 20% to 95%, Absolute humidity: 36 g/m³ |
| Operating Temperature/Humidity | –5 °C to +60 °C (23 °F to 140 °F) / 20% to 80%, Absolute humidity: 36 g/m³ |
| Power Requirements | 6 V to 12 V DC |
| Power Consumption | 3.0 W (When the motor operates: 4.0 W) |
| Mass | Approx. 275 g (10 oz.) |
| Dimensions | 50 × 60 × 93.3 mm (2 × 2 3/8 × 3 3/4 in.) (W/H/D) |
