| Specifications | Details |
| Dimensions | 130 mm x 120 mm |
| Weight | 160.8g (without enclosure) |
| Supported Battery Types | LiPo: 10 – 14S LiS: 15 – 20S LiFe: 10 – 14S |
| Battery Inputs | Main: 30 to 50 VDC |
| Power Outputs | 3.3V: 1A 5V: 20A 7.4V: 20A 12V: 15A 28V: 2A |
Key Features:
- Dual Battery Inputs: Provides seamless, automatic switching between two battery sources for continuous power.
- Multiple Outputs: Configurable power outputs tailored for avionics, servos, and payloads.
- Monitoring Capabilities: RS232 serial or CAN access enables real-time monitoring of voltage, current, and internal temperature.
- Enclosure Options: Available in both slimline and rugged IP66-rated enclosures, customizable with various connector options.
- Reverse Protection: Safeguards against incorrect battery connections.
