Specifications

• FOUR AN231E04 dpASP with header pins and user-selectable inter FPAA connections.
• Serial (USB) interface that allows ”plug and play” connectivity using a standard serial cable between the development board and a PC running AnadigmDesigner®2 software.
• SPI (or host processor) interface, allowing you to interface the dpASP directly to your digital board
• Includes pre-laid out options to add a "Rauch Filter" to FPAA Input's and smoothing filters to FPAA outputs
• A large breadboard area for building your specific interface circuitry PCB is pre-built with the provision of the addition resistor and capacitor which can be used for a Rauch filter at the input or output.
• Easy choice of 1, 2, 3 or 4 FPAA's to be configured, to enable multi-chip system evaluation.
• On-board 16-MHz or 40MHz clock source for FPAA Analog clock input.
• Ideally suited to the development of the embedded system, the board contains a 32bit 80Mhz (3rd Party) microcontroller, 5 pin access to re-program this uC, the board is prepared and wired for a standard 16x2 LCD (Not supplied).
• The development board is supplied with four AN231E04 FPAA's you can use the board with AnadigmDesigner®2 software Version 2.8.0.1 or later to implement designs for any dpASP or FPAA in the 3.3volt family.
